LoDi-GA 10k 3-Leiter
The LoDi-GA 10k 3-rail is a board used for wagon detection on three-rail track when you run the LoDi-8-GBM as an occupancy detector with RailCom.
It can be mounted directly under the track, with simple wiring to solder pads.
Features of the LoDi-GA 10k 3-rail
- Board with a 10k resistor built in
- For wagon detection on three-rail track with occupancy reporting
- Available in packs of ten
1. The LoDi 5-way distribution board and its connections
Out of our own long experience, and that of our partners who wire up customer layouts on site every day. Our small tie point for joining cables by solder pad.
Any kind of cable can be quickly unsoldered and soldered back on . . .
The board has a screw hole so it can simply be mounted. It can also be glued, depending on the mounting situation on your layout.
2. Technical data
The LoDi 5-way distribution board carries a total of 5 amperes.
0–60 volt AC or DC input
| Property | Value |
|---|---|
| Dimensions | Length: 20 mm |
| Width | 16 mm |
| Height | 1.5 mm at its highest point |
| Weight | 1 g |
