LoDi-Shift-Commander

To connect the LoDi-Rektor to the LoDi-Con, proceed as follows:

First tap the "house", which always takes you back to the main screen.

From there go to "Settings" > "Command station" >

To connect the LoDi-Shift-Commander to the LoDi-Con, proceed as follows:

The LoDi-Con now searches the network for compatible command stations. Any it finds are shown.

That is because the LoDi-Rektor understands the z21 protocol as well, so that a Roco Wi-Fi handheld can connect to it. In this case please use the LoDi-Rektor.

Now choose the Shift-Commander you want to connect to the LoDi-Con. In our example it is the top one.

You can change the name of the Shift-Commander if you like.

The LoDi-Con now connects to the LoDi-Rektor.

The LoDi-Con now connects to the Shift-Commander.

A new symbol (LSC) for the LoDi-Shift-Commander now has to appear at the top left. If that LSC is steady, the connection is up. If it blinks, the LoDi-Con has no connection to the

LoDi-Shift-Commander or is trying to establish one.

Tapping the top left takes you to the overview of command stations, which also shows whether a connection is active. You can now tap the Shift-Commander to see its IP address and status.

Once the LoDi-Shift-Commander is set up, no further steps are needed. You can now reach every article created in the Shift-Commander straight from the

turnout and signal symbol.

Routes can also be created for the
