LoDi-Verteiler 2*3
Introducing:
The LoDi distribution board series.
On the layout, and in other extra-low-voltage applications, you regularly need to split a line quickly and simply — a common return, say, or the positive pole of a model railway transformer that then feeds house lighting, and so on . . .
That is what we created the LoDi distribution board series for.
With these modules you can distribute the cables easily over screw terminals.
Please note: always work with ferrules where you can.
You will find those and the matching model railway cable in our LoDi shop shortly.
Features of the LoDi distribution board 2*3
- A simple distribution strip with screw terminals, maximum 10 amperes at a maximum of 60 volts.
1. The LoDi distribution board and its connections
The LoDi distribution board 2*3 has nine terminals wired through. Only one conductor can be distributed per output. On the board each output is marked with a 1.
2. Technical data
The LoDi distribution board 2*3 carries a total of 10 amperes.
0–60 volt AC or DC input
| Property | Value |
|---|---|
| Dimensions | Length: 35 mm |
| Width | 25 mm |
| Height | 13 mm at its highest point |
| Weight | 10 g |
